Product title:New Smart automatic cleaning ion air blower ZK-KF-40AH with double head

  • Product detail:air blower with two fan, automatic cleaning ion air blower

    New product kesd automatic cleaning ion blower ZK-KF-40AH with double head



    Product Description

    New product kesd automatic cleaning ion air blower KF-40AH with double headNew product kesd automatic cleaning ion air blower KF-40AH with double head



    New product kesd automatic cleaning ion air blower KF-40AH with double head

    Technical parameters

    Product model

    KF-40AH

    Input power supply

    AC220V/50Hz or AC110V/60Hz

    LED indicator light

    Fan normal operation

    If the fan operates normally, the green indicator light is on

    Fan abnormal operation

    If the fan operates abnormally, the red indicator light is on

    High voltage normal

    If high voltage operates normally,the green  indicator light is on

    High voltage abnormal

    If high voltage operates abnormally,the red indicator light is on

    Ion balance

    Automatic ion balance system 0±10V

    Cleaning timer set

    Can be set within the range of 0-999 hours

    Voltage impose

    High frequency AC method/±2200V

    Air volume

    2.56-4.07m³/min(single head)

    Ozone

    Below 0.03(distance 150mm)

    Applied

    0~40℃(no condensation)

    Applied

    30-70% RH (no water drop condensation)

    Overall size /mm

    400*82*150(exclouding stents)

    Weight

    3.04Kg (exclouding stents)



    Anti-static test condition

    Operating voltage:DC24V Test voltage:±1000V-±100V Ambient temperature:23℃±2℃

               Distance

    300mm

    600mm

    900MM

    Destaticizing time

    Positive

    1.0s

    2.3s

    4.0s

    Negative

    1.2s

    2.8s

    4.4s

    Residual voltage

    Positive

    <0±10V

    Negative
